Cr10Ni90 Nickel Chromium Wire Resistance Heating Wire Ni90 10 Nicrome Wire

CHANGZHOU LIANGRU INTERNATIONAL TRADE CO., LTD.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap Cr10Ni90 Nickel Chromium Wire Resistance Heating Wire Ni90 10 Nicrome Wire from wholesalers

    Buy cheap Cr10Ni90 Nickel Chromium Wire Resistance Heating Wire Ni90 10 Nicrome Wire from wholesalers
    • Buy cheap Cr10Ni90 Nickel Chromium Wire Resistance Heating Wire Ni90 10 Nicrome Wire from wholesalers
    • Buy cheap Cr10Ni90 Nickel Chromium Wire Resistance Heating Wire Ni90 10 Nicrome Wire from wholesalers
    • Buy cheap Cr10Ni90 Nickel Chromium Wire Resistance Heating Wire Ni90 10 Nicrome Wire from wholesalers
    • Buy cheap Cr10Ni90 Nickel Chromium Wire Resistance Heating Wire Ni90 10 Nicrome Wire from wholesalers

    Cr10Ni90 Nickel Chromium Wire Resistance Heating Wire Ni90 10 Nicrome Wire

    Ask Lasest Price
    Brand Name : Runlai
    Model Number : Cr10Ni90
    Certification : ISO9001 ROHS
    Price : Negotiable
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 300 tons per month
    Delivery Time : 20~40 Days
    • Product Details
    • Company Profile

    Cr10Ni90 Nickel Chromium Wire Resistance Heating Wire Ni90 10 Nicrome Wire

    Cr10Ni90 Nickel Chromium Wire Resistance Heating Wire Ni90 10 Nicrome Wire With Good Electrical Conductivity


    Product Introduction


    Cr10Ni90 wire is a high resistance electric heating alloy wire composed of about 90% nickel and 10% chromium. It has excellent corrosion resistance and high temperature stability. The maximum operating temperature can reach 1300℃, the melting point is about 1400℃, the density is 8.7g/cm³, and the elongation at break is ≥20%. Its resistivity is relatively low, usually lower than that of Cr20Ni80 alloy. Cr10Ni90 wire has excellent processing performance and is easy to be machined by wire drawing, forming and other mechanical processing, and can be made into resistance wires of different shapes. In addition, the alloy wire also has good flexibility and weldability, and is easy to install and maintain. It is widely used in the fields of electric heating elements, resistance elements, thermocouple materials, such as electric kettles and oven heaters in household appliances, high temperature heaters in industrial heating equipment, and heating equipment in corrosive environments.


    Size dimension range:


    Wire: 0.01-10mm

    Ribbons: 0.05*0.2-2.0*6.0mm

    Strip: 0.05*5.0-5.0*250mm

    NiCr series: Cr10Ni90,Cr20Ni80, Cr30Ni70, Cr15Ni60, Cr20Ni35, Cr20Ni30


    Parameter


    Performance materialCr10Ni90
    ComposiciónNi90
    Cr10
    Fe
    Temperatura máxima1300
    Punto de fusion 1400
    Densidad g/cm38.7
    Resistividad μΩ·m,200.76±0.05
    Alargamiento a la ruptura≥20
    Calor especifico J/g.
    Conductividad térmica KJ/m.h
    Coeficiente de expansión de líneas a×10-6/(201000℃)
    Estructura micrográfica
    Propiedades magnéticas

    FormSpecification
    WireDiameter=0.025mm~8mm
    Flat wireWidth=0.40~6.0mmThick=0.03~0.50mm
    Stripwidth=8~250mmThick=0.05~3.0mm
    BarDiameter=8~100mmLong=50~1000

    Specific Applications


    1. Electric Heating Elements:Cr10Ni90 wire is commonly used to manufacture various electric heating elements, such as heating wires in electric furnaces, heat treatment equipment, and household appliances. Its high resistivity and good corrosion resistance enable it to work stably in high temperature environments.
    2. Resistor Elements:This material is also suitable for manufacturing general resistor elements, such as voltage regulating resistors and brake resistors, and is widely used in various motor and electrical appliance industries.
    3. Thermocouples:Cr10Ni90 wire can be used to manufacture thermocouples for temperature measurement and control. Its high resistivity and stable resistance characteristics enable it to provide accurate temperature measurement in high temperature environments.
    4. Aerospace Field:Due to its high high temperature strength, good oxidation resistance, and strong corrosion resistance, Cr10Ni90 wire is also used in high temperature components in the aerospace field, such as heating elements in aircraft engines and rocket engines.
    5. Nuclear Industry Field:In nuclear reactors, Cr10Ni90 wire can be used to manufacture key components such as reactor pressure vessels, heat exchangers, and pipelines due to its excellent corrosion resistance and high temperature stability.

    Advantages and Characteristics


    • High resistivity:Cr10Ni90 wire has high resistivity, which enables it to generate a lot of heat when current passes through it, and is suitable for manufacturing electric heating elements.
    • Good corrosion resistance:This material has good corrosion resistance and can remain stable in a variety of harsh environments. It is suitable for manufacturing equipment that works in high temperature, high pressure, and corrosive environments.
    • High temperature stability:Cr10Ni90 wire still maintains good mechanical properties and corrosion resistance in high temperature environments, and can operate stably for a long time under high temperature conditions above 800 degrees Celsius.

    Contact Us

    Email:fbwlau@cnrunlai.com

    Oem service:
    Welcome customized size
    We are experience factory for OEM&ODM service

    Support and Services:


    Our Nichrome Alloy product comes with technical support and services to ensure optimal performance and customer satisfaction:

    • Expert consultation on product selection and application
    • Technical assistance for installation and maintenance
    • Product testing and analysis for quality control
    • Customized solutions for unique customer needs
    • Training and education on product use and safety

    We are committed to providing our customers with the highest level of support and service for our Nichrome Alloy product.

    Packing and Shipping:


    Product Packaging:

    • The Nichrome Alloy product will be packaged securely in a durable cardboard box to ensure safe transport.
    • The product will be wrapped in protective bubble wrap to prevent any damage during shipping.
    • A label with the product name and details will be placed on the box for easy identification.

    Shipping:

    • The product will be shipped via a reputable courier service within 2 business days of receiving the order.
    • Customers will receive a tracking number once the product has been shipped.
    • Please allow 5-7 business days for delivery.
    • If there are any issues with the product or shipping, please contact our customer service team for assistance.

    Related Questions and Answers


    Can Cr10Ni90 Wire be customized?
    Cr10Ni90 Wire can be customized according to the specific needs of customers, including diameter, length and packaging method.


    What is the standard packaging method of Cr10Ni90 Wire?
    Cr10Ni90 Wire is usually wound on a white ABS spool and wrapped with plastic film, and then packed in a carton. Customized packaging according to customer requirements is also accepted.


    How is the corrosion resistance of Cr10Ni90 Wire?
    Due to its high nickel content, Cr10Ni90 Wire has excellent corrosion resistance and is particularly suitable for use in corrosive environments.


    What are the mechanical properties of Cr10Ni90 Wire?
    Cr10Ni90 Wire has good machinability and is easy to machine, such as wire drawing and forming, and can produce resistance wires of different shapes according to application requirements.
