High Temperature Electrical Resistance Nichrome Wire Cr15Ni60 Wire 1.12 μΩ·m Resistivity

Product Introduction

Cr15Ni60 Wire is a high resistance electric heating alloy wire composed of 15% chromium and 60% nickel, with excellent high temperature resistance, oxidation resistance and resistance stability. Its main chemical composition also includes a small amount of carbon, silicon, manganese, phosphorus, sulfur and aluminum, with a density of 8.2 g/cm³, a melting point between 1368-1405℃, a resistivity of 1.12 μΩ·m (20℃), and a thermal expansion coefficient of 13.0×10⁻⁶/°C (20-1000°C). Cr15Ni60 Wire is widely used in the manufacture of heating elements, electric heating wires, resistance strips, etc., especially for periodic heat treatment furnaces below 900℃, high-grade electric heating tubes, household electric heaters, chemical equipment and high-temperature parts in the aerospace field.

Size dimension range:

Wire: 0.01-10mm

Ribbons: 0.05*0.2-2.0*6.0mm

Strip: 0.05*5.0-5.0*250mm

NiCr series: Cr10Ni90,Cr20Ni80, Cr30Ni70, Cr15Ni60, Cr20Ni35, Cr20Ni30

Parameter

Specific Applications

1. Heating elements: Cr15Ni60 is widely used in the manufacture of heating elements, especially in periodic heat treatment furnaces below 900°C. It has good oxidation resistance and thermal strength at high temperatures, and can maintain its performance for a long time.
2. Heating wire: Due to its high nickel content, Cr15Ni60 has excellent resistance and heat resistance, so it is often used in high-end electric heating tubes and high-end household electric heaters.
3. Resistance band: In high-quality resistance boxes, Cr15Ni60 can be used as a resistance band, providing stable resistance values ​​and good heat resistance.
4. Chemical equipment: In the chemical industry, the alloy is used to manufacture high-temperature and corrosion-resistant equipment and pipelines, especially in acidic or sulfur-containing atmospheres, where its corrosion resistance makes it an ideal choice.
5. Aerospace: In the aerospace field, Cr15Ni60 is used to manufacture high-temperature components of engines, which can withstand extreme temperatures and pressures due to its good oxidation resistance and heat resistance.

Advantages and Characteristics

• High temperature adaptability: The melting point of Cr15Ni60 Wire is about 1390℃, and it can operate stably in the temperature range of 800℃ to 1200℃. Its resistance performance remains stable at high temperatures, making it an ideal choice for high-temperature operating environments.
• Low expansion coefficient: The linear expansion coefficient of Cr15Ni60 Wire is about 17.0×10^-6/°C (in the temperature range of 20°C to 1000°C), which means that even when the temperature fluctuates, the dimensional change of the alloy is small, which helps to reduce structural problems caused by thermal stress and enhance the reliability of the equipment.
• Excellent mechanical properties: The tensile strength of Cr15Ni60 Wire is not less than 600 Mpa, and the elongation is at least 20%. Such mechanical properties ensure its stability when subjected to force, and it is not easy to undergo plastic deformation. At the same time, it is also easy to form during processing to meet diverse manufacturing needs.
• Processing convenience: Cr15Ni60 Wire exhibits good plasticity at room temperature, which is convenient for cold processing, such as stretching, bending and stamping. It can be easily made into components of various shapes and sizes, providing convenience for customized production.

Contact Us

Email:fbwlau@cnrunlai.com

Oem service:
Welcome customized size
We are experience factory for OEM&ODM service

Support and Services:

Our Nichrome Alloy product comes with technical support and services to ensure optimal performance and customer satisfaction:

• Expert consultation on product selection and application
• Technical assistance for installation and maintenance
• Product testing and analysis for quality control
• Customized solutions for unique customer needs
• Training and education on product use and safety

We are committed to providing our customers with the highest level of support and service for our Nichrome Alloy product.

Packing and Shipping:

Product Packaging:

• The Nichrome Alloy product will be packaged securely in a durable cardboard box to ensure safe transport.
• The product will be wrapped in protective bubble wrap to prevent any damage during shipping.
• A label with the product name and details will be placed on the box for easy identification.

Shipping:

• The product will be shipped via a reputable courier service within 2 business days of receiving the order.
• Customers will receive a tracking number once the product has been shipped.
• Please allow 5-7 business days for delivery.
• If there are any issues with the product or shipping, please contact our customer service team for assistance.

Related Questions and Answers

Q: What are the physical properties of Cr15Ni60 Wire?
A: The resistivity of Cr15Ni60 Wire is about 1.25×10⁻⁶Ω·m, the melting point is about 1370°C, the applicable temperature range is 700°C to 1100°C, and the linear expansion coefficient is about 17.0×10⁻⁶/°C (20°C-1000°C).
Q: What are the mechanical properties of Cr15Ni60 Wire?
A: The tensile strength of Cr15Ni60 Wire at room temperature is ≥600MPa, and the elongation is ≥20%. At high temperatures, especially in high temperature environments around 1000°C, it can still maintain good mechanical strength and resistivity.
Q: What is the oxidation resistance of Cr15Ni60 Wire?
A: Cr15Ni60 Wire exhibits excellent oxidation resistance in high temperature environments. The increase in chromium content enables the alloy to form a stable oxide layer in an oxidizing atmosphere, effectively preventing further oxidation of the alloy itself. The oxidation rate at 1000°C is extremely low, and it can work in high temperature environments for a long time without losing performance.
