Heat Treatment Elongation 30% Incoloy Alloy 800H Strip In Chemical Industry

Product Introduction

Incoloy Alloy 800H strip is widely used in the chemical industry, mainly due to its excellent corrosion resistance and high temperature performance. The main components of this alloy include nickel (30-35%), chromium (19-23%) and iron (balance), as well as small amounts of aluminum (0.15-0.60%) and titanium (0.15-0.60%). The combination of these components allows Incoloy 800H to maintain good mechanical properties and chemical stability at high temperatures. Its physical properties include a density of 8.0 g/cm³ and a melting point range of 1350-1400℃. In the chemical industry, Incoloy 800H strip is often used to manufacture equipment such as reactors, heat exchangers, evaporators, etc., which often need to withstand high temperatures and corrosive media. The corrosion resistance of Incoloy 800H is especially good in high temperature environments. It has excellent tolerance to corrosive media such as oxidation, sulfidation, and chlorination. In addition, Incoloy 800H strip has good processing properties and can be processed by conventional metal processing processes such as forging, rolling, drawing, etc. These characteristics make Incoloy 800H strip an indispensable material in the chemical industry, ensuring the long-term stable operation of equipment in high temperature, high pressure and corrosive environments.

Parameter

1. High temperature reactor: Incoloy 800H strip is used to manufacture high temperature reactors, which can operate for a long time in harsh environments such as high temperature, high pressure, and strong corrosion. Its excellent oxidation resistance and corrosion resistance make it an ideal choice.
2. Acidic medium reactor: In reactors that handle acidic media such as sulfuric acid, hydrochloric acid, and hydrofluoric acid, Incoloy 800H strip can effectively resist corrosion and extend the life of the equipment.
3. High temperature heat exchanger: Incoloy 800H strip is used to manufacture high temperature heat exchangers, which can maintain stable performance under high temperature and high pressure conditions and effectively resist corrosion and oxidation.
4. Chemical heat exchanger: In chemical production, heat exchangers need to withstand the dual test of high temperature and corrosive media. Heat exchanger tube bundles made of Incoloy 800H strip can effectively improve heat exchange efficiency and extend the service life of equipment.
5. High temperature distillation tower: Incoloy 800H strip is used to manufacture high temperature distillation towers, which can operate stably for a long time under high temperature and high pressure environments and effectively resist corrosion.

Advantages and Characteristics

• Density and specific heat: The density of Incoloy 800H alloy is 7.94 g/cm³ and the specific heat is 460 J/kg-°K.
• Elastic modulus and thermal conductivity: Its elastic modulus is about 196.5 GPa and its thermal conductivity is 18.3 W/m-°K.
• Melting point range: The melting point range of Incoloy 800H alloy is 1357 to 1385°C.
• Good processability: Incoloy 800H alloy can be easily welded and processed by standard manufacturing processes, has good cold forming properties, and is suitable for the manufacture of bellows, expansion joints and other equipment.
• Heat treatment performance: The alloy has good stability and processability during heat treatment, and can meet various forming, welding and other process requirements.
• High temperature performance: Incoloy 800H alloy has excellent creep resistance and oxidation resistance at high temperatures. In a 100,000-hour creep test at 700°C, the creep rupture time of Incoloy 800H is significantly longer than other conventional stainless steels and nickel-based alloys.

Contact Us

Email:fbwlau@cnrunlai.com

Oem service:
Welcome customized size
We are experience factory for OEM&ODM service

Related Questions and Answers

Q: What are the main characteristics of Incoloy Alloy 800H strip?
A: Incoloy Alloy 800H strip has excellent oxidation resistance, carburization resistance and high temperature strength, and can maintain stable performance in high temperature and corrosive environments.

Q: What is the chemical composition of Incoloy Alloy 800H strip?
A: Incoloy Alloy 800H strip is mainly composed of nickel (30.0-35.0%), chromium (19.0-23.0%), iron (minimum 39.5%), carbon (0.05-0.10%), aluminum (0.15-0.60%) and titanium (0.15-0.60%).

Q: In what fields is Incoloy Alloy 800H strip used?
A: Incoloy Alloy 800H strip is widely used in petrochemical, aerospace, nuclear energy, power and metallurgy, such as high temperature reactors, heat exchangers, furnace tubes, turbine engine parts, etc.

Q: What are the mechanical properties of Incoloy Alloy 800H tape?

A: Incoloy Alloy 800H tape has a tensile strength of 77,000 psi (531 MPa), a yield strength of 29,000 psi (200 MPa), a hardness of 126 Brinell, and an elongation of 52%.

Q: What are the physical properties of Incoloy Alloy 800H tape?

A: Incoloy Alloy 800H tape has a density of 0.287 lb/in³ (7.94 g/cm³), a specific heat of 0.11 BTU/lb-°F (460 J/kg-°K), an elastic modulus of 28.5 x 10⁶ psi (196.5 GPa), and a melting point range of 2475-2525°F (1357-1385°C).
