    Chemical Industry STM B168 UNS N06600 Inconel 600 Foil With High Temperature Resistance

    Ask Lasest Price
    Brand Name : Runlai
    Model Number : Inconel 600
    Certification : ISO9001 ROHS
    Price : Negotiable
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 300 tons per month
    Delivery Time : 20~40 Days
    • Product Details
    • Company Profile

    Chemical Industry STM B168 UNS N06600 Inconel 600 Foil With High Temperature Resistance

    Chemical Industry STM B168 UNS N06600 Nickel-Chromium Alloy 600 Foil With High Temperature Resistance


    Product Introduction


    Inconel 600 strip has a wide range of applications in the chemical industry, mainly due to its excellent corrosion resistance and high temperature stability. This nickel chromium iron-based high-temperature alloy can resist the corrosion of strong acids, strong bases, salts and other corrosive media, and is suitable for manufacturing chemical reactors, catalyst carriers, distillation towers, heat exchangers, heating furnaces, pipelines and other equipment. Its high nickel content endows it with good corrosion resistance, while the presence of chromium enhances its antioxidant capacity, forming a protective oxide film under high-temperature oxidation conditions, thereby slowing down the corrosion rate. In addition, Inconel 600 maintains good mechanical properties at high temperatures and can withstand temperatures up to 1100 ° C without losing strength, making it an ideal material choice for high temperature and corrosive environments.


    Parameter


    Chemical Properties of Inconel 600


    CCrNi+CoAlTiFeNb+TaMnSiPSCu
    ≤0.1514.0~17.0≥72≤0.35≤0.506.0~10.0≤1.0≤1.0≤0.5≤0.04≤0.015≤0.5

    ITEMθ/℃TENSIE STRENGTHHBS
    σb/MPaσP0.2/MPaδ5/%φ/%
    BAR/ROD20≥585≥240≥30-134~217
    RING20≥520≥205≥35-≥187
    HOT ROLL PLATE20≥550≥240≥35≥40-
    900≥95≥45≥40≥50-
    COLD ROLLED SHEET20≥550≥240≥30--
    900≥90≥40≥60--
    COLD ROLLED SHEET20≥550≥200≥30--
    STRIP20≥550≥240≥30--
    WIRE20-HV≤151

    Shape
    Size(mm)
    WIre
    0.5-7.5
    Rod/Bar
    8.0-200
    Strip
    (0.5-2.5)*(5-180)
    Tube
    custom made
    Plate
    custom made

    Specific Applications


    Inconel 600 Strip is widely used in the chemical industry to manufacture various corrosion-resistant equipment and components, including:

    • Chemical reactor: used for manufacturing chemical reactors that can withstand the erosion of corrosive media such as strong acids, strong bases, and salts.
    • Catalyst carrier: As a catalyst carrier, it ensures stability in high temperature and corrosive environments.
    • Distillation tower: used to manufacture distillation towers that can withstand high temperatures and corrosive gases.
    • Heat exchanger: used for manufacturing heat exchangers that can maintain efficient heat exchange performance in high temperature and corrosive environments.
    • Heating furnace: used for manufacturing heating furnaces that can maintain stable performance in high temperature environments.
    • Pipeline: Used for manufacturing pipeline systems that can withstand the erosion of highly corrosive media, ensuring the long-term service life of pipelines.

    Advantages and Characteristics


    1. High temperature resistance performance:Inconel 600 maintains good mechanical properties in high temperature environments and can withstand temperatures up to 1100 ° C without losing strength. This makes it an ideal choice for high-temperature conditions, such as applications in engine components and combustion chambers.The thermal expansion coefficient of this alloy is relatively low, which means that its size changes less when the temperature changes. This characteristic enables it to maintain a stable shape in high-temperature applications, reducing structural damage caused by thermal expansion.
    2. Corrosion resistance:Inconel 600 has excellent oxidation resistance and corrosion resistance, and can work stably in acidic and alkaline environments. Its chromium content forms a protective oxide film under high-temperature oxidation conditions, thereby slowing down the corrosion rate. This characteristic makes it highly favored in industries such as chemical processing and petroleum refining.The alloy is highly effective in treating hydrogen chloride and chlorine gas at high temperatures; Hydrogen chloride can reach about 538 ° C, and chlorine gas can be safely used up to 510 ° C. For nitrogen, hydrogen, and carburizing, this alloy also has excellent corrosion resistance and is therefore used in various heat treatment furnaces.
    3. Good processing performance:Inconel 600 has excellent welding and forming properties and can be processed through various methods such as cold working and hot working. This characteristic makes the material very convenient for manufacturing complex shaped components.This alloy has good machinability, although its high strength characteristics make mechanical processing relatively difficult, it can still achieve the manufacturing of complex components through reasonable processing techniques and tool selection. In the market, many companies have developed specialized processing tools for Inconel 600 to improve processing efficiency.
    4. Mechanical properties:Inconel 600 exhibits excellent strength and toughness under both room temperature and high temperature conditions. Its yield strength and tensile strength are relatively high, making it perform well when subjected to mechanical stress. In addition, the alloy can maintain relatively high ductility at high temperatures, reducing the risk of brittle fracture.This alloy has good fatigue resistance and creep resistance, and can maintain stable performance in environments that can withstand alternating loads and high-temperature creep for a long time.

    Summary


    Inconel 600 Strip has become an indispensable material in the chemical industry due to its excellent high temperature resistance, corrosion resistance, good processing performance, and mechanical properties. Its stability and reliability in high temperature and corrosive environments enable it to perform excellently in manufacturing various key equipment and components, ensuring the long-term service life and safety of chemical equipment.


    Contact Us

    Email:fbwlau@cnrunlai.com

    Oem service:
    Welcome customized size
    We are experience factory for OEM&ODM service


    Related Questions and Answers


    Q:What are the main features of Inconel 600 strip?
    A:Inconel 600 strip has excellent high temperature and corrosion resistance, good mechanical strength and toughness, and is easy to process and weld.

    Q:What are the main application areas of Inconel 600 strip?
    A:Inconel 600 strip is widely used in fields such as aerospace, chemical, nuclear energy, oil and gas extraction, and food processing.
    Q:What is the chemical composition of Inconel 600 strip?
    A:The main chemical components of Inconel 600 strip are nickel (72%), chromium (14-17%), and iron (6-10%).
    Q:What are the mechanical properties of Inconel 600 strip?
    A:Inconel 600 strip has good mechanical properties at both room temperature and high temperature, with high tensile strength and yield strength.
    Q:What is the price of Inconel 600 strip?
    A:The price of Inconel 600 strip varies depending on specifications, size, quantity, and market supply and demand, and is usually higher.
